Lewitt LCT 640 TS

RM4,403.00

Available on backorder

*Special Order





Capture the scene

Change the polar-pattern – even after the recording.

A TRUE NEXT-GEN STUDIO MICROPHONE

Freely change the polar pattern in postproduction

Designed and engineered in Austria, the LCT 640 TS will revolutionize the way we think about the recording process. Since the signal of the front and back diaphragm is provided by independent circuitries, any kind of polar pattern can be realized dynamically - even after the recording.

Think about all the possibilities!

The ultimate freedom of choice is not to choose at all.



Revolutionary Dual Output Mode

The LCT 640 TS provides the signal of the front and the back diaphragm of the capsule separately. In addition to your standard XLR cable plug in the included adapter cable and experience all the possibilities of this true next-gen microphone. Use both outputs to capture the whole session instead of committing to a single source.

Change the material you have already recorded dynamically by adjusting the polar pattern, add or subtract room, and even turn your microphone by 180°.

Think about all the possibilities!







POLARIZER plug-in

Change pattern in your DAW

After recording with the LCT 640 TS, use our plug-in to change the pattern. Jump back and tweak your material.



Standard Multi-Pattern Mode

Plug in one 3-pin XLR and you have a large diaphragm multi-pattern condenser mic featuring the following polar patterns: omni, wide cardioid, cardioid, supercardioid and figure-8



Magnetic Pop Filter

Hides nothing, captures everything - except plosives and hisses.

This efficient magnetic pop filter will effectively reduce pops and hisses without covering 2/3rds of your vocal artist's face. The most subtle and convenient way of getting the most out of every single recording.



MS Stereo with one LCT 640 TS?

Definitely!

Usually, mid side stereophony can only be done with two microphones. But now, it is way easier to use one LCT 640 TS. Just point the side of the microphone to the signal source and record both outputs on a stereo track in your DAW. Change the panorama for both signals to adjust the stereo width.



Perfect Match technology

The future of stereo recording

Any two LCT 640 TS will always form a matched pair. Add another one and you will get a "matched triplet", and so on. Every single LCT 640 TS undergoes a series of measurements followed by adjustment of the polarization voltage to achieve exactly the same sensitivity in every microphone.



Clipping History

Innovative features make life easier

It is easily possible to miss if clipping occurred during the recording. Clipping History lets you know if the microphone clipped since it was last turned on.



Low-cut and attenuation

Adapt to every situation

Low-cut: linear, 40 Hz, 80 Hz, 160 Hz

Attenuation: 0 dB, -6 dB, -12 dB, -18 dB



Change the polar-pattern - even after the recording

Designed and engineered in Austria, LEWITT’s new LCT 640 TS will revolutionize the way we think about the recording process. Set to Dual Output Mode the signal of the mics front and back diaphragm is provided by independent circuitries, any kind of polar pattern can be realized dynamically - even after the recording. Already recorded material can be changed dynamically by adjusting the polar pattern - room sound can be added or decreased, even a turn by 180° is possible. After recording with the LCT 640 TS you can use LEWITT’s Polarizer plug-in to tweak the material with incredible ease of use. In Multi-Pattern Mode the LCT 640 TS has all the well-known characteristics of a great sounding studio multi-pattern condenser mic. It features five polar patterns: omni, wide cardioid, cardioid, supercardioid and figure-8. Perfect Match technology takes care that all LCT 640 TS will always form a matched pair. The Dual Output Mode allows to record Mid Side stereo with only one LCT 640 TS - usually only possible with two microphones. Clipping History, 4 low-cut and pre-attenuation settings round off the outstanding feature list of the LCT 640 TS. The LCT 640 TS opens doors to a new world of recording techniques.

Specifications

Acoustical operating principle: Pressure gradient transducer, externally polarized

Diaphragm: 3 micron gold sputtered Mylar

Transducer Ø: 25.4 mm, 1 in

Polar pattern (Dual Output Mode): Create any polar pattern in post-production

Polar pattern (Multi-Pattern Mode): omni, wide cardioid, cardioid, supercardioid, figure-8

Sensitivity: 31.4 mV / Pa (-30.1 dBV), cardioid, 30.3 mV / Pa (-30.3 dBV), omni, 34.1 mV / Pa (-29.4 dBV), figure-8

Signal / noise ratio: 83.5 dB (A)

Equivalent noise level: 10.5 dB (A), cardioid

Dynamic range: 123.3 dB (A)

Max. SPL for 0.5 % THD: 133.8 dBSPL, 0 dB pre-attenuation

Pre-attenuation pad: 0 dB, -6 dB, -12 dB, -18 dB

Low-cut filter: linear , 40 Hz (12 dB/oct), 80 Hz (12 dB/oct), 160 Hz (6 dB/oct)

Internal impedance: 110 Ω

Rated load impedance: 1.000 Ω

Supply voltage: 48 V /- 4 V

Current consumption: 5.1 mA

Mic enclosure: Zinc die cast

Connector: Gold plated 3-pin XLR Mini 3-pin XLR

Microphone dimensions: 158 x 52 x 36 mm, 6.22 x 2.04 x 1.42 in

Microphone net weight: 425 g / 14.9  oz

* A "Special Order" is a product that we normally do not keep in stock. We order it from the manufacturer as soon as you order from us. We are the exclusive distributor for Lewitt, so we can get your special order to you fast, in about 2-3 weeks. Remember that special orders are non-cancelable, so make sure the item you are ordering is correct. Call us at 65 63388657 if you need assistance.
