Universal Audio Teletronix LA-2A Classic Leveling Amplifier

*Special Order



“It’s very hard to go wrong with an LA-2A. It just has that sound.” - Peter Katis (The National, Interpol, Jónsi)

"The reissue sounds just as good, I swear, and has become a daily-used tool at my studio. Vocals are reigned in without getting all squashed, bass evens out in the nicest way, guitars sound fuller.." - Larry Crane, Tape Op

"It's easy to dial in great sounds with the LA-2A. Operation is so straightforward you'd have to be in a coma to get stumped. The LA-2A's uniquely transparent processing makes it incredibly effective for treating vocals. When you need to warm up a piercing or thin vocal and smooth its uneven dynamics, the LA-2A can work miracles. It also sounds awesome on bass guitar and, for a certain type of sound, on kick drum. And did I mention that it looks beautiful, too? If I were a mutant, I'd give the LA-2A three thumbs up!" - Michael Cooper, Mix Magazine





True to the original design, UA’s famed tube-amplified T4 electro-optical compressor.



Now You Can:

• Dial-in legendary optical tube compression textures for vocals, bass, drums, and more
• Easily add iconic warmth and tube limiting with simple, easy-to-use controls
• Record your tracks through vintage UA, "handmade in the USA," circuits
• Track and mix with a piece of audio recording history



The Teletronix Story

Teletronix founder Jim Lawrence first used photocells for controlling audio gain in the early 1960s. His ingenious optical compression design was a technological breakthrough, far surpassing the stability and transparency of earlier circuits. Universal Audio founder M.T. ”Bill” Putnam later purchased this patented technology, continuing to manufacture the LA-2A for years to come.



The Real Deal



Key Features

True to the original in design, manufacturing and performance
Lag free, distortion free optical attenuator system
Distortion less than 0.5% THD
0 to 40 dB gain limiting
Balanced stereo interconnection
Frequency response 1 dB, 30 to 15,000 cps
Output level of 10 dBm and 40 dB gain
Low noise – less than 70 dB below ±10 dBm output



Technical Specifications

Input Impedance
50, 150, 250, 600 ohms

Output Load Impedance
50, 150, 250, 600 ohms

External Connections
Jones Barrier terminals and XLR connectors

Frequency Response
+0/-1 dB 30 Hz to 15kHz

Gain
40 dB ±1dB

Input Level
+16 dB maximum

Output Level
+10 dB nominal, +16 dB maximum

Distortion
Less than 0.5% THD (0.25% typical) at ±10 dBm

Noise
70 dB below +10 dBm output level

Attack Time
10 microseconds

Release Time
0.06 seconds for 50% release; 0.5 to 5 seconds for complete release

Meter
dB gain reduction and dB output

Power Requirements
35 watts, 120/240 volts, 50/60 Hz

Dimensions
19" Rackmount chassis, 3U

Weight
5.9 kg
